DEYE 125KW, Three Phase String Inverter
SUN125kW | Three Phase String Inverter
Features:
- 8 MPP trackers, Max. efficiency up to 98.8%
- Zero export application, VSG application
- String intelligent monitoring (optional)
- Wide output voltage range
- Anti-PID function (Optional)
- Type II DC/AC SPD
- DEWA approved
Datasheet:
|
Models |
SUN-120K-G01P3 |
SUN-125K-G01P3 |
SUN-130K-G01P3 |
SUN-135K-G01P3 |
SUN-136K-G01P3 |
|
Input Side |
|||||
|
Max. DC Input Power (kW) |
180 |
187.5 |
195 |
202.5 |
204 |
|
Max. DC Input Voltage(V) |
1100 |
||||
|
Start-up DC Input Voltage (V) |
250 |
||||
|
MPPT Operating Range (V) |
200-1000 |
||||
|
Max. DC Input Current (A) |
40+40+40+40+40+40+40+40 |
||||
|
Max. Short Circuit Current (A) |
60+60+60+60+60+60+60+60 |
||||
|
No. of MPP Trackers |
8 |
||||
|
No.of Strings per MPP Tracker |
4+4+4+4+4+4+4+4 |
||||
|
Output Side |
|||||
|
Rated Output Power (kW) |
120 |
125 |
130 |
135 |
136 |
|
Max. Active Power (kW) |
132 |
135 |
135 |
135 |
136 |
|
Nominal Output Voltage / Range (V) |
3L/N/PE 220/380V, 230/400V |
||||
|
Rated Grid Frequency (Hz) |
50 / 60 (Optional) |
||||
|
Operating Phase |
Three Phase |
||||
|
Rated AC Grid Output Current (A) |
181.9/174 |
189.4/181.2 |
197/188.5 |
204.6/195.7 |
206.1/197.2 |
| Max. AC Output Current (A) |
200/191.4 |
204.6/195.7 |
204.6/195.7 |
204.6/195.7 |
206.1/197.2 |
|
Output Power Factor |
>0.99 |
||||
|
Grid Current THD |
<3% |
||||
|
DC Injection Current (mA) |
<0.5% |
||||
|
Grid Frequency Range |
45~55 or 55~65 (Optional) |
||||
|
Efficiency |
|||||
|
Max. Efficiency |
98.8% |
||||
|
Euro Efficiency |
98.3% |
||||
|
MPPT Efficiency |
>99% |
||||
|
Protection |
|||||
|
DC Reverse-Polarity Protection |
Yes |
||||
|
AC Short Circuit Protection |
Yes |
||||
|
AC Output Overcurrent Protection |
Yes |
||||
|
Output Overvoltage Protection |
Yes |
||||
|
Insulation Resistance Protection |
Yes |
||||
|
Ground Fault Monitoring |
Yes |
||||
|
Anti-islanding Protection |
Yes |
||||
|
Temperature Protection |
Yes |
||||
|
Integrated DC Switch |
Yes |
||||
|
Remote Software Upload |
Yes |
||||
|
Remote Change of Operating Parameters |
Yes |
||||
|
Surge Protection |
DC Type II / AC Type II |
||||
|
General Data |
|||||
|
Cabinet Size (WxHxD mm) |
1006×516×325.5 (Excluding Connectors and Brackets) |
||||
|
Weight (kg) |
103 |
||||
|
Topology |
Transformless |
||||
|
Internal Consumption |
<1W (Night) |
||||
|
Running Temperature |
-25-60℃, >45℃ Derating |
||||
|
Ingress Protection |
IP65 |
||||
|
Noise Emission (Typical) |
≤65 dB |
||||
|
Cooling Concept |
Smart Cooling |
||||
|
Permissible Altitude (m) |
4000 |
||||
|
Designed Lifetime |
>20 Years |
||||
|
Operating Surroundings Humidity |
0-100% |
||||
|
Features |
|||||
|
DC Connection |
MC-4 Mateable |
||||
|
AC Connection |
IP65 Rated Plug |
||||
|
Display |
LCD 240 × 160 | ||||
|
Interface |
RS485/RS232/Wifi/LAN |
||||
5 Years + 2 years Nastech exclusive = 7 Years
- single or three-phase:
- three-phase
- Frequency:
- 50
- Voltage:
- 380
