Huawei 12KW Smart PV Controller

Technical Specification

SUN2000-12KTL-M5

SUN2000-15KTL-M5

SUN2000-17KTL-M5

SUN2000-20TL-M5

SUN2000-25KTL-M5

Efficiency

Max. efficiency

98.4%

European weighted efficiency

97.9%

98.0%

98.1%

98.1%

98.2%

Input

Recommended max. PV power 1

18,000 Wp

22,500 Wp

25,500 Wp

30,000 Wp

37,500 Wp

Max. input voltage 2

1100 V

Full-load MPPT voltage range

370V~800V

410V~800V

440V~800V

480V~800V

530V~800V

MPPT Operating voltage range 3

200 V ~ 1000 V

Start-up voltage

200 V

Rated Input voltage

600 V

Max. input current per MPPT

30 A (two string) / 20 A (single string)

Max. short-circuit current

40 A

Number of MPP trackers

2

Max. number of inputs

4

Output

Grid connection

Three phase

Rated output power

12,000 W

15,000 W

17,000 W

20,000 W

25,000 W

Max. apparent power

13,200 W

16,500 W

18,700 W

22,000 W

27,500 W

Rated output voltage

220 Vac/ 380 Vac, 230 Vac/ 400 Vac, 239.6 Vac/ 415Vac, 3W + N + PE

Rated AC Grid Frequency

50 Hz / 60 Hz

Max. output current

18.2A/380Vac

25.2A/380Vac

28.6A/380Vac

33.6A/380Vac

42.0A/380Vac

17.3A/400Vac

23.9A/400Vac

27.1A/400Vac

31.9A/400Vac

39.9A/400Vac

16.7A/415Vac

23.1A/415Vac

26.1A/415Vac

30.8A/415Vac

38.5A/415Vac

Adjustable power factor

0.8 leading ... 0.8 lagging

Max. total harmonic distortion

≤3 %

Features & Protections

Overvoltage Category

PV Ⅱ/AC Ⅲ

Input-side disconnection device

Yes

Anti-islanding protection

Yes

AC over-current protection

Yes

DC reverse-polarity protection

Yes

String fault detection

Yes

DC surge protection

TYPE II

AC surge protection

CLASS II

Residual current monitoring unit

Yes

Arc fault protection

Yes

Ripple control ripple control

Yes

Integrated PID recovery 4

Yes

General Data

Operation temperature range

-25 ~ + 60 °C (-13 °F ~ 140 °F)

Relative humidity

0 % RH ~ 100% RH

Max. operating altitude

0 ～4,000 m (13,123 ft.) (Derating above 2000 m)

Cooling

Smart air cooling

Display

LED Indicators; Integrated WLAN + FusionSolarApp

Communication

RS485; WLAN/Ethernet via Smart Dongle-WLAN-FE (Optional)

4G / 3G / 2G via Smart Dongle-4G (Optional)

Weight (with mounting plate)

21kg (46.4 lb)

Dimensions (W x H x D)

(incl. mounting plate)

546 x 460 x 228mm (21.5 x 18.1 x 9.0 inch)

Degree of protection

IP66

Optimizer Compatibility

DC MBUS compatible optimizer

SUN2000-450W-P, SUN2000-450W-P2, SUN2000-600W-P, SUN2000-1300W-P, SUN2000-1100W-P

Standard Compliance (more available upon request)

Safety

EN/IEC 62109-1,EN/IEC62109-2

Grid connection standards

G99,EN50549,CEI0-21,CEI0-16,VDE-AR-N-4105,VDE-AR-N-4110,C10/11,ABNT, VFR2019,UNE 217001, UNE 217002,RD 244, TOR D4,IEC61727,IEC62116
