Huawei LUNA2000-215-2S10 Smart String ESS

Energy Storage System Parameters

Model type

LUNA2000-215-2S10

Rated capacity

215.0kWh

Maximum cycle rate

0.5 CP

Maximum cycle efficiency

91.3%

Depth of charge and discharge

0~100%

Dimensions (W x D x H)

1150mm×1800mm×2100mm

Weight

≤ 2.8 T

Operating temperature range

-30 °C ~ 55 °C (＞50°C Derating)

Storage temperature range

-35 °C ~ 60 °C

Operating humidity range

0 ~ 100% (non-condensing)

Maximum operating altitude

4,000 m

System temperature control mode

Hybrid cooling

Balance mode

Active balance

SOC calibration mode

Automatic

Fire suppression mode

Directional gas exhaust, Top explosion vent, Aerosol

Auxiliary power supply

176~264 Vac，single phase，≤5 kW

Power consumption standby

≤150 W

Communication port

Ethernet / Optical fiber

Communication protocol

Modbus TCP

Protection degree

IP55

EMC protection rating

Class B

Noise (rated operating condition)

65 dB(A)

Lightning protection

Type II (AC port)

Protection mode

Anti-islanding protection, residual current detection, insulation resistance detection, AC overcurrent

protection, and AC cable connection protection

Environment

RoHS6

Certification standards

UL9540A; UN38.3; IEC 62477-1; IEC 62040-1; IEC 61000-6-1/2/3/4; IEC61727

Battery Parameters (DC)

Cell material

LFP

Rated battery capacity

280Ah

System battery configuration

240S1P

Number of battery packs

4

Operating voltage range

648~864 V

Rated DC current

140 A

PCS Parameters (AC)

PCS model type

PCS2000-108K-MB1

Rated output power

108 kW

Rated AC current

164.1 A

AC voltage & frequency

380 / 400 / 415 V (3P4W)，50 / 60 Hz

Adjustable power factor range

-1 ... +1

AC current harmonics THDi (rated operating condition)

≤1.5 %
