Ulica 580 Watt Double Glass Bi-facial N-Type Solar Panel

Ulica Solar
SKU:
UL-580M-144DGN
Availability:
4-6 weeks

Log in for pricing

Weight:
32.00 KGS
Width:
113.40 (cm)
Height:
227.80 (cm)
Depth:
30.00 (cm)
Current Stock:

DOUBLE‑GLASS BIFACIAL N‑TYPE 580 Watt

Features:

  • Global Tier 1 brand as announced by Bloomberg NEF
  • Lower LCOE
  • Lower Shading and resistive loss
  • Lower temperature coefficient
  • Outstanding mechanical load resistance 3800Pa wind load, 5400 Pa snow load
  • Anti-PID(potential induced degradation
  • Passed anti-PID test under 85% damp heat 85% relative humidity for 96 hours
  • Great Durability against extreme conditions
  • Passed salt mist corrosion test. Ammonia corrosion test, dust & sand test, fire test, all certified by TUV

Datasheet:

Electrical Specification

MODEL TYPE

UL-570M-144DGN

UL-575M-144DGN

UL-580M-144DGN



STC*

NOCT*

STC

NOCT

STC

NOCT

Maximum Power (Pmax)

W

570

425

575

428

580

432

Maximum Power Voltage (Vmp)

V

42.20

38.8

42.30

38.9

42.40

39.0

Maximum Power Current (Imp)

A

13.51

10.94

13.59

11.01

13.68

11.08

Open-circuit Voltage (Voc)

V

50.74

46.1

50.88

46.2

51.02

46.4

Short-circuit Current (Isc)

A

14.23

11.48

14.31

11.55

14.40

11.62

Module Efficiency STC

%

22.07

22.26

22.45

Operating Temperature

-40 °C - 85 °C

Maximum System Voltage

DC1500V (IEC)

Maximum Series Fuse Rating

25A

Power Tolerance

0-+5 Watt

Temperature coefficients of Pmax

-0.30%/ °C

Temperature coefficients of Voc

0.250%/ °C

Temperature coefficients of Isc

0.046%/ °C

Nominal Operating Cell Temperature (NOCT)

43±2°C

*STC : Cell Temperature : 25°C, Irradiance : 1000 W/m2 , Air mass : 1.5G

*NOTC : Air Temperature : 20°C, Irradiance : 800 W/m2 , Air mass : 1.5G, Wind speed : 1m/s

Specification

Cell Type

182x91mm N Type Mono-crystallin

No. of cells

144 (6x12x2)

Dimensions

2278x1134x30mm

Weight

32kg

Glass

2m, Anti-reflection Coating, High Transmission, Low Iron, Tempered Glass

Junction Box

IP68,3diodes

Connector

MC4 Compatible

Cable Length (Including connector)

4mm2

Portrait : (+) 400mm/(-)200mm

Landscape : (+) 1400mm/(-)1400mm

Packaging Configurations

Two Box= One Pallet

36pcs/box,72pcs/pallet,720pcs/40HQ container

Electrical Characteristics with different rear side power gain (reference to 570W front)

Pmax/W

Voc/V

Isc/A

Vmp/V

Imp/A

Pmax gain

570

50.7

14.23

42.2

13.51

0

599

50.7

14.94

42.2

14.18

5%

627

50.7

15.65

42.2

14.86

10%

656

50.7

16.36

42.2

15.53

15%

684

50.7

17.08

42.2

16.21

20%

713

50.7

17.79

42.2

16.88

25%

741

50.7

18.5

42.2

17.56

30%





15-year product warranty 30-year linear power warranty
Peak Power Watts:
580
Mono or Bi-Facial:
Bi-Facial
